Fujinon HA42 x 13.5 BERD
Stabilized High Definition Super Telephoto ENG Style lens for large venues or sporting events. Comes with lens support bracket. Digital servo remote control for full servo studio control, robotics, jibs, tower cams, teleconferencing and other applications
Stabilized High Definition Super Telephoto ENG Style lens for large venues or sporting events. Comes with lens support bracket. Digital servo remote control for full servo studio control, robotics, jibs, tower cams, teleconferencing and other applications where remote control of zoom, focus and iris via RS-232 serial data or traditional analog control is desired. Remote control of the 2X extender is possible with the optional model ECU-2A remote extender module. With integrated stabilizer.
- Focal length : 13.5 ~ 570mm
- Zoom ratio : 42x
- Extender : 2xMaximum relative aperture
- 1:2.8 (13.5 ~307mm)
- 1:5.2 (570mm)
- Minimum object distance (M.O.D.) : 2.8mObject dimensions at M.O.D. (1x)
- 13.5mm: 1888 x 1061mm
- 570mm: 45 x 25mmObject dimensions at M.O.D. (2x)
- 27mm: 944 x 530mm
- 1140mm: 22 x 13mmAngular field of view (1x)
- 13.5mm:39°07' x 22°35'
- 570mm: 0°58' x 0°33'Angular field of view (2x)
- 27mm: 20°08' x 11°24'
- 1140mm: 0°29' x 0°16'
- Macro : Yes
- Filter thread : M127 x 0.75
- Size (diameter x length) : 130 x 358,5mm
- Mass(without lens hood) : 5.4kg
- Operating system : RD
- Option -
- Memo : Inner Focus, Zoom limit, built-in OS TECH
General
- Marque Fujinon
- Référence HA42X13.5BERD-U48
Features
- Monture objectif 2/3"
Specific references
- UPC : 493874
